Furnace Ignition Repair in Chicago, IL

Ignition repair for furnaces that click, glow or try to light and fail: igniters, flame sensors and gas valves.

  • ✓Owner-operated
  • ✓Shop on W Irving Park Rd
  • ✓Gas and electric furnaces

Quick answer: if your furnace clicks, glows or tries to light and then gives up, the problem is almost always in the ignition path: the igniter, the flame sensor, the gas valve or a safety switch blocking the burners. Call (773) 514 3683 and describe the sequence you hear and see.

Read the symptom

Clicks, no flame: spark igniter, gas supply or gas valve. Igniter glows orange, no flame: gas valve or no gas reaching the burners. Flame for a few seconds, then shutoff: dirty or failing flame sensor. Draft inducer runs, igniter never starts: pressure switch or control board. No glow, no click: power, control or door switch.

Hot-surface versus spark ignition

Most furnaces installed in the last few decades use a hot-surface igniter, a fragile ceramic element that cracks with age, or a spark igniter that clicks. Both depend on a clean flame sensor to prove the flame. The flame sensor is a thin rod in the burner flame; residue on it makes the board shut the gas off after a few seconds.

Older homes

The median home in ZIP 60634 was built in 1952 (ACS 2020-2024), so some furnaces still have standing pilots. See our pilot light page for those. This page covers electronic ignition.

What you can safely do

Replace the filter, check the thermostat is on heat, and make sure the furnace switch and front panel are in place. Reset once if it has locked out. Do not keep resetting, because unburned gas can collect around the burners, and do not touch gas fittings.

Gas safety

If you smell gas, leave and call Peoples Gas at 866-556-6002 from outside. For carbon monoxide leave and call 911.

What we check first

We watch the start-up sequence, then test the igniter for resistance, clean and test the flame sensor, check the pressure switch and gas valve. Call (773) 514 3683 and tell us what you hear and how many times it tries to light.

Technician insight

In Chicago 60634 the thing that catches most people out with Furnace Ignition Repair is the age of the wiring in pre-1960 bungalows along Irving Park Road. Rodents chew the 18-gauge control wires inside the cabinet and the new igniter fails within weeks because voltage never reaches it.

No-heat call on a 1958 bungalow

Homeowner reported the furnace attempting to start but shutting down after 30 seconds. Inspection showed a cracked hot-surface igniter and rodent-damaged wiring at the control board. Replaced the igniter, repaired the harness with high-temp wire, and confirmed steady flame signal across three cycles.

Furnace Ignition Repair Services We Offer

✓Hot-surface Igniter Replacement

Replace a cracked or weak igniter that glows but never lights the burners.

✓Flame Sensor Cleaning or Replacement

Fix a furnace that lights and then shuts off after a few seconds.

✓Gas Valve Testing

Test the valve that supplies gas to the burners during ignition.

✓Pressure Switch and Draft Inducer Checks

Test the safety circuit that must prove the vent before ignition starts.

Furnace Ignition Repair Cost in Chicago 60634, IL

Service Typical Range What Affects It
Flame sensor cleaning $95–$150 Price rises if sensor must be replaced.
Hot surface igniter replacement $180–$320 Depends on igniter material and furnace access.
Pilot assembly service $200–$375 Higher when thermocouple and orifice both need replacement.
Ignition control board $350–$550 Includes board plus labor; model-specific pricing applies.

Ranges are typical for Chicago 60634, IL and confirmed with an exact written quote before any work starts.

How it works

  1. 1

    Watch the sequence

    We observe each start-up step to find where it stops.

  2. 2

    Test the part

    We test the igniter, sensor, valve and switches instead of guessing.

  3. 3

    Written quote

    You approve the price in writing before any part is replaced.

  4. 4

    Confirm a clean light

    We run several cycles to confirm a reliable light-off.

Pricing

We give a written quote after testing; the price depends on the failed part and access to the furnace.

Furnace Craft Co — Furnace Repair in Chicago 60634

Good to know

Furnace Ignition Repair — FAQs

Still have questions? We're happy to talk it through.

(773) 514 3683
+ Why does my furnace click but not light?
A failing igniter, a gas supply issue or a blocked pressure switch are common causes. We test each.
+ Why does it light and then shut off?
That is the flame sensor pattern: the flame is not being proven. Cleaning or replacing the sensor is the usual fix.
+ How long do igniters last?
They wear with use and can crack from age. We test one before replacing it.
+ Is this different from a pilot light problem?
Yes. Standing pilots use a thermocouple and a different fix.
+ Is it safe to keep resetting the furnace?
Reset once. If it fails again, stop and call us.
